Background Music System IMM-2320V2 (B)

The IMM-2320V2 Media Preamp/Mixer combines a 3-input stereo mixer with 2 microphone inputs and an internal media player. The auto-talkover feature of the microphone section allows automatic attenuation of the music signal by an adjustable amount when speaking into a microphone. This makes the unit a perfect companion for fitness instructors or presenters who have no hand free to lower the program level while speaking. The internal media player sports an IR remote for added comfort; it also features a jingle player, which runs both in a one-shot and a scheduled mode. Two master outputs with fire evacuation facilities like external mute and emergency signal priority functions complete the feature set of this comprehensive unit. The IMM-2320V2 is the ideal core unit for fitness sound systems, hospitality sound systems and mobile sound systems deployed for educational or promotional applications. Also available with additional built-in Bluetooth module as IMM-2320V2B.

FEATURES

2 stereo inputs with signal-present-LED, rear-panel gain and
front-panel level control
Front panel 3.5mm stereo TRS input
2x Mic inputs with rear-side 1/4” TRS connectors
Voice-specific 2-Band EQ plus “on air” switches for mic inputs
Adjustable auto talk-over for automatic music level reduction
when microphone is used
Internal media player/tuner with file/folder access for USB
thumbdrives/SD cards up to 16GB/2000 songs, MP3 file name
readout on large LCD display, regular and random play
sequence, elapsed/remain time mode, FM tuner mode with RDS
station display, jingle player with up to 3 jingles and additional
scheduled play mode
Two stereo main outputs with independent level control
2-Band front-side EQ for main output 1
10 LED level meter for main output 1
Rear-side adjustable maximum level control for each output
Rear-side tone control for main output 2
Mono switch and 100Hz HP filter on rear side for main output
Balanced TRS and Phoenix output connectors for both outputs; additional unbalanced RCA connectors
Emergency input which shuts down master output when emer-gency signal comes in and plays emergency signal instead
Output mute contact to externally mute the output
Headphone section with volume control and front-side 6.3mm stereo jack
Unbalanced record output
Internal wide-voltage swing linear power supply for excellent audio dynamics
Full metal case with brushed aluminum front panel and detach-able rack ears
AC mains voltage selector switch 115/230V
CE/ROHS compliant
Available as IMM-2320V2 without Bluetooth module and as IMM-2320V2B with Bluetooth module

TECHNICAL DATA

Signal/Noise.............................＞82dB (Line)
Crosstalk Damping....................＞65dB (Line)

THD......................................＜0.05% (Line)

Frequency response.................20Hz – 20 kHz

AC IN (230V setting).......AC220-250V~ 50Hz

AC IN (115V setting).......AC110-120V~ 60Hz

Power consumption........................max. 18W

Dimensions.....482.6(427)xH44.5xD152.0mm
(parentheses = without rack ears)

Weight...............................................2.6 kg

LOGISTICS DATA
IMM-2320V2 (without Bluetooth module)
Order Number................................2005511

Single unit EAN-13..............5060502920508

IMM-2320V2B (with Bluetooth module)
Order Number................................2005521

Single unit EAN-13..............5060502920515

Single Carton size.................535x255x90mm

Single Carton gross weight....................3.1kg

Units per master carton..............................4

Master carton size...................560x285x390

Master carton gross weight.................13.4kg
