Background Music System IMA-400V2 (B)

The IMA-400V2 media amplifier combines a MP3 player, a FM Tuner and a multitude of microphones and stereo sources with a high-headroom stereo power amplifier in one compact unit. Add a VCA volume remote control option for its main output, the IMA-400V2 extends the its applications into venues with more complex requirements. With the additional zone output, the unit can be configured to either use the internal amplifier as a stereo amplifier and an external amplifier for the zone signal, or to use the internal amplifier as a dual mono unit, one for the main and one for the zone signal. A music on-hold output allows to feed the unit’s music program into a telephone system. Adding the seamless integration with fire evacuation systems, the IMA-400V2 is the default choice of any mid-scale venue operator. Also available with additional built-in Bluetooth module as IMA-400V2B.

FEATURES

Mixer section with 1x music and 3x microphone sources
Music source switchable: Media player/tuner, 3 external line inputs (with gain control) and front-side 3.5mm TRS line input
Internal media player/tuner with file/folder access for USB thumbdrives/SD cards up to 16GB/2000 songs, MP3 file name
readout on large LCD display, regular and random play sequence, elapsed/remain time mode, FM tuner mode with RDS station display, jingle player with up to 3 jingles and additional scheduled play mode
Microphone inputs with phantom power, isolation transformer (only Mic 1), LPF & Gain (rear), volume & EQ controls (front) and on/off switch
Adjustable auto talk-over for automatic music level reduction
Master section with 2-Band EQ plus 5-LED output level meter
Additional rear-side maximum level control for master
Remote volume control option via external potentiometer
Chime sound generator with adjustable volume, external trigger and user-loadable sound on memory card
Zone section with separate volume control assignable to master signal or to two of the rear-side line inputs
Two independent mono amplifier blocks with 160W@4Ohms / 100W@8Ohms RMS power each

TECHNICAL DATA

Power (RMS) stereo...2×100/160@8/4 Ohms

Signal/Noise.............................＞82dB (Line)

Crosstalk Damping....................＞65dB (Line)

THD......................................＜0.05% (Line)

Frequency response.................20Hz – 20 kHz

AC IN (230V setting).......AC220-250V~ 50Hz

AC IN (115V setting).......AC110-120V~ 60Hz

Power consumption......................max. 350W

Dimensions........W483.0×H88.5×D228.0mm

Weight................................................tba kg

LOGISTICS DATA

IMA-400V2B (with Bluetooth module)
Order Number................................2007701

Single unit EAN-13..............5060502920300

Single Carton size...............535x350x180mm

Single Carton gross weight.................9.85 kg

Units per master carton..............................2

Master carton size..............560x390x375mm

Master carton gross weight................20.9 kg
